Vortex Tube Cooling System

With no moving parts a vortex tube spins compressed air to separate the air into cold and hot streams by forcing the compressed air through a generation chamber which spins the air centrifugally along the inner walls at a high rate of speed toward the control valve.

Vortex tube cooling system. If i were to tell you that i can take a supply of ordinary compressed air and drop it s temperature by 50 f without any type of refrigerant or electrical connection you might be scratching your head a bit. Vortex tubes convert compressed air into a stream of cold air. The cooling capacity of the vortex tube should be taken into account first when selecting the vortex tube. They have no moving parts for a long service life.

A vortex tube creates cold air and hot air by forcing compressed air through a generation chamber which spins the air at a high rate of speed 1 000 000 rpm into a vortex. Cooling or heating with the vortex tube. The cooling effect is obtained by balancing the temperature value and the air flow. Exair cabinet coolers incorporate a vortex tube to produce cold air from compressed air with no moving parts.

Vortex electric enclosure cooling systems are available in cooling capacities ranging from 400 btu hr to 5000 btu hr. The compact cabinet cooler can be installed in minutes through a standard electrical knockout. 117 to 1465 watts. Use them to keep heat sensitive electronic equipment cool with cold air.

Nema 12 ip54 cabinet coolers are available in many cooling capacities for large and small control panels. 1 6 deg c. Pressurised gas is injected tangentially into a swirl chamber and. It has no moving parts.

The meech air cooling range has been designed to provide effective cooling for any number of applications. Running solely on compressed air meech vortex tubes separate the inlet air into two air flows one very hot the other very cold. The electrical enclosure cooling thermostat model maintains tight control on the temperature setpoint of 3 deg f. Airflow adjusters sold separately can be switched out to increase or decrease the vortex tube s airflow cfm to alter its cooling capacity.

In addition as the air pressure entering the vortex increases and the dryness level increases the vortex tube increases its efficiency. The vortex tube also known as the ranque hilsch vortex tube is a mechanical device that separates a compressed gas into hot and cold streams. Vortex tubes are an effective low cost solution to respiratory cooling needs. Air that rotates around an axis like a tornado is called a vortex.
